Warn XD9 Winch

Long time best selling winch from WARN

• Comes with synthetic rope, hook, remote control on 12’ (3.7m) lead, hand-held wireless remote (optional) and polished aluminum hawse fairlead.
• Series-wound, high-speed motor provides fast line speed and strong pulls
• Low-profile design and separate control box allows for a wide range of mounting options
• Next-generation contactor control pack delivers long duty cycles and exceptional durability
• Durable 3-stage planetary geartrain for smooth, reliable, operation
• Exclusive brake design provides superior control while winching
• Newly designed hand-held remote control
• Chip-resistant, powder-coated finish

Additional information

General specifications:

• Brand: Warn
• Model: XD9
• Rated line pull: 9,000 lbs. (4080 kgs.) single-line
• Motor: 12V Gen II, Series Wound
• Electrical controls: Contactor
• Remote Control: Remote switch, 12‚Äô (3.7m) lead and hand-held wireless (optional)
• Length: 55,5 cm
• Width: 16,0 cm
• Height: 19,3 cm
• Weight: 38,0/27,0 kg

For more specifications:

Spec Sheet Warn XD9 Winch Steel Rope

Spec Sheet Warn XD9 Winch Syntethic Rope



Shipping specifications:

• Length: 60,0 cm
• Width: 20,0 cm
• Height: 22,0 cm
• Weight: 39,0/28,0 kg
